2014-2017 Honda TRX500 Foreman Service Repair Manual
The same manual is used by proffesional mechanics and technicians to repair and diagnose your 2014 2015 2016 2017 Honda TRX500 Foreman ATV. Provides most complete service & repair information available.
This manual covers 10 types of TRX500 models:
FM1 -left foot operated gearshift
FM2 – Left foot operated gearshift/Electric Power Steering (EPS)
FM5 – Left fool operated gearshift/Independent rear suspension
FM6 – left fool operated gearshift/Electric Power Steering (EPS)Jlndependent rear suspension
FM7 – Left foot operated gearshift/Electric Power Steering (EPS)Jlndependent rear suspension/Aluminum wheel
FE1 – Electric shift program (ESP)
FE2 – Electric shift program (ESP)/Electric Power Steering (EPS)
FA5 – Dual clutch transmission (DCT)/lndependent rear suspension
FA6 – Dual clutch transmission (DCT)/Electric Power Steering (EPS)/lndependent rear suspension
FA7 – Dual clutch transmission (DCT)/Electric Power Steering (EPS)/lndependent rear suspension/Aluminum wheel
For 2014 it covers all model variations except Rubicon models. For 2015-2017 it covers all model variations including Rubicon models.
Manual is in PDF format.
Hi quality, 56 MB, almost 700 pages, has clickable chapters. PDF has no restrictions on printing or saving/burning to disc.
Covers complete tear down and rebuild, pictures and part diagrams, maintenance, troubleshootingetc…
Manual includes:
GENERAL INFORMATION
FRAME/BODY PANELS/EXHAUST SYSTEM
MAINTENANCE
PGM-FI SYSTEM
IGNITION SYSTEM
ELECTRIC STARTER
FUEL SYSTEM
COOLING SYSTEM
LUBRICATION SYSTEM
CYLINDER HEAD/VALVE
CYLINDER/PISTON
CLUTCH/GEARSHIFT LINKAGE (FM/FE models)
DUAL CLUTCH TRANSMISSION (DCT: FA models)
SUB-TRANSMISSION (FA models)
ALTERNATOR/STARTER CLUTCH
CRANKCASE/TRANSMISSION/CRANKSHAFT/BALANCER
ENGINE REMOVAL/INSTALLATION
FRONT WHEEL/SUSPENSION/STEERING
REAR WHEEL/SUSPENSION
BRAKE SYSTEM
FRONT DRIVING MECHANISM
REAR DRIVING MECHANISM
BATTERY/CHARGING SYSTEM
LIGHTS/METERS/SWITCHES
ELECTRIC SHIFT PROGRAM (ESP: FE models)
ELECTRIC POWER STEERING (EPS: FM2/FM6/FM7/FE2/FA6/FA7)
WIRING DIAGRAMS
